AC Three-phase 36kVa non-residential enclosure

ACTri-SCH-63-300mA set

The set consists of :

• Plastic case 2x12 modules, 436x310x148mm,
• IP65
1
• Socomec M63 4P 63A switch-disconnector with front operation
1
• Set of spring terminals (distributor)
1
• Schneider iC60N 4P 63A Courbe C Icc10kA + Differential 63A-300mA type AC
• (inverter protection)
1
• Fuse holder DF Electric 10x38 4P 32A 400v AC + 3 fuses 10x38 32A 400v Gg (
• surge arrester
• protection
• )
1
• Citel surge arrester 4P 400v AC type 2 common mode and differential
,
• In20kA Imax40kA
1
• Earth terminal block :
• 2x16mm2 + 5x10mm2
• Output from switch-disconnector up to 35mm2 copper
• Wiring
• Cable glands
