External Enwitech protection box for SolarEdge
€1,738.59
Tax included
10013682/Révision 1.0
0768563817625
The "NL/BE" external protection cabinet should be used exclusively in configuration with a SolarEdge "StorEdge" single-phase inverter with "SE5000-RWS" Backup function.
The external protective cabinet, the components used and the electrical wiring were tested and approved by the manufacturer SolarEdge.
"External protection box for SolarEdge "StorEdge"
• Application: "StorEdge" Backup System - SolarEdge
• PV/battery-compatible inverter: StorEdge SE5000-RWS
• Earth-linking scheme: TT or TN-S scheme; 1ph or 3ph (230/400V 50Hz) Connection: 1ph (230V/N)
• Separation of the network: All poles
Size
Technical data
| Characteristics | |
| Rated tension AC [V] | 1ph -230 (L/N) |
| Public network/building connection [V] | 1AC or 3AC 230/400 |
| Isolation nominal tension [V] | 400 |
| Frequency of operation [Hz] | 50 |
| Switchable short-circuit current max. [kA] | 10 |
| Authorized land link scheme (customer system) | TT/TN-S |
| Earth-linking scheme in Backup mode | TN-S |
| Phase coupling (Backup mode) | (impossible) |
| Maximum consumer power allowed [kW] | 4.5 (7 short-term - 300s) |
| Maximum crossing thermal power [kW] | 12 (consumers - inverter) |
| Losses on standby [W] | about 7 |
| General data | |
| Dimensions (LxHxP) [mm] | 448x432x161 |
| Weight [kg] | 10 |
| Operating temperature range [C] | -20..40 |
| Transport/storage temperature [C] | -25..-55 |
| Short-term maximum 24 hours [C] | -25..-60 |
| Condenser moisture | X |
| Humidity - permissible range [%] | 5 ... 95 |
| Maximum installation altitude above sea level [m] | 2000 |
| IP Protection Index (EN 60529) | 65 |
| Outdoor installation | X |
| Type of installation | Inside |
| Protective class (EN 61140) | Ⅱ |
| Case material | Polycarbonate |
| RoHS Compliance (2011/65/EU) | • |
| Case colour | Similar to RAL7046 |
| Type of assembly | Wall mounting |
| Cover | Transparent |
| Type of closure (actuation) | Without tools |
| Standards/Standards | |
| Set of equipment | 61439-1 61439-2 61439-3 |
| Stationary electrical energy storage systems | VDE-AR-E 2510-2 |
| Other | |
| Tariff number | 85371098 |
